Brake Disc MX03423702
MATRIX PRO part number MX03423702 – Brake Disc for Range Rover. Wholesale supply – add it to your quote list and send us the full list for prices and stock.
The brake disc turns with the wheel and is gripped by the pads to stop the car. Replace discs when they are below minimum thickness, warped (vibration when braking) or deeply scored.
Specifications
- Fitting Position: Rear Axle
- Weight [kg]: 5.2
- Height [mm]: 50.8
- Outer diameter [mm]: 302
- Number of mounting bores: 1
- Rim Hole Number: 5
- Brake Disc Thickness [mm]: 11
- Brake Disc Type: Solid
- Bolt Hole Circle Ø [mm]: 108
- Minimum thickness [mm]: 9
- Centering Diameter [mm]: 63.6
- Wheel Bolt Bore Ø [mm]: 15.8
OE numbers
LR027123
Vehicle fitment
- LAND ROVER RANGE ROVER EVOQUE (L538)
- RANGE ROVER EVOQUE Convertible (L538)
- RANGE ROVER EVOQUE VAN (L538)
